System configurator and order-information guide
Start PRIMERGY R450
PRIMERGY R450 Status 2003-10-24
Section
I
Basic unit
Rack basic unit 4U including
The PRIMERGY R450 basic unit comes with:
1 x Xeon MP CPU
- 3 power supply module, hot-plug redundant
2 channel
- 2 channel HD PBay with 3 HD bays each
- 1 floppy disk drive 1,44MB
S26361-K845-V200
1,5GHz 1 MB TLC
- 2 hot-replace and redundant fans
S26361-K845-V201
1,9GHz 1 MB TLC
- a CPU Board for up to 4x Xeon CPUs
S26361-K845-V202
2 GHz 2 MB TLC
- a Memory Board for 16 memory slots
- I/O section with
- System Management Processor
- Dual LVD/U3W-SCSI controller (Adaptec 7899)
- VGA graphics 8 MB ATI
- LAN 10/100 Mbit with RJ45 connector (Intel 82559)
- 5 64bit / 100 MHz PCI-x slots, 1 64bit / 66 MHz slot, all hot-plug
- 2 32bit / 33 MHz long PCI slots
- ServerStart packet incl. ServerBooks CD,
ServerSupport CD and ServerView
Mounting kit for PRIMERGY R450
- 1 pair of telescopic rails (730-810mm)
- 1 pair of carrier rails
- 1 bracket PC-Rack
- 1 cable management PC-racks
Mounting kit for mounting of servers in FSC 19" PRIMECENTER- racks
and all server racks conforming to EIA standard EIA-310-D for 19" racks.
Therefore the mounting kit is variable in deepth from 730-810mm
PRIMERGY PRIMECENTER- Rack
External Interfaces
External Interfaces for ServerManagement
SNP:SY-F1647E301-P
2 x RS-232-C (serial, 9 pin)
1 x RS-232-C (serial, 9 pin)
Installation ex works for one
1x Centronics (parallel, 25 pin,
1 x RJ45 LAN
server or subsystem.
EPP/ECP compatible)
1 x Power Jack
Hereby the rack will be delivered
1 x keyboard (PS/2)
completely pre-mounted and
1 x mouse (PS/2)
all wired connections are tested.
1 x VGA (15 pin)
With racks 12U, 24U, 38U:
1 x USB Frontside
Systems and components
2 x USB Backside
will be delivered installed in the rack
1 x RJ45 LAN
With racks 46U:
Systems and components
will be delivered separately
"Rack-mounting ex factory"
To be ordered only together with
This service is to be ordered once
a PRIMERGY-
per installable server/storage
PRIMECENTER rack
subsystem, in order to get the
e.g.:
server/storage subsystem
S26361-K826-V10x
mounted into the PRIMERGY racks.
refer configurator PC-Rack
In case of the 46 U PRIMERGY Rack,
max. 1x per System
this service has to be ordered,
to get the mounting kits and the
cables installed
PRIMERGY 42/23U Rack
important notice !
This kit can be ordered,
the mounting kit for PRIMERGY R450
if it is planned to mount the rack
is included the basic version and
version in an already available
will be delivered with every R450
FSC 42/23U rack
S26361-F1331-L141
Mounting kit for 42/23U rack
- 1 pair of carrier rails
- 1 pair of telescopic rails
- 1 cable carrier
max. 1x per system
A
Fujitsu Siemens Computers
Enterprise Products - PRIMERGY Server
5 of 12
