System configurator and order-information guide
A PRIMERGY R450 Status 2003-10-24
There are 3 bays for hot-plug power supplies, each with 500W
Each basic unit contains 3 modules and provides redundancy
for a fully equipped system
Section II Processor
A mix of processors with different clock frequency and different On-Chip cache cannot be used
The multi-processor system premises a multi-processor operating system
Terminators are not necessary
S26361-F2817-E151 S26361-F2817-E191 S26361-F2817-E202
XEON MP 1,5GHz XEON MP 1,9GHz XEON MP 2GHz
up to with 1 MB TLC on Chip, with 1 MB TLC on Chip, with 2MB TLC on Chip,
3x heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention"
occupies slot for one CPU occupies slot for one CPU occupies slot for one CPU
max. 3x per system max. 3x per system max. 3x per system
Section III Memory
There are 16 memory slots available (4 banks, 4 modules each)
They can optionally be equipped with 128 MB, 256 MB, 512 MB or 1GB registered DDR-RAM modules (PC1600)
The maximal extension is 16 GB with today available 1GB modules!
Any mix of modules within one memory bank is not allowed
ECC with memory scrubbing and chipkill is standard
Optional hot-spare memory functionality can be configured in the BIOS (redundant memory bank 3 + 1)
S26361-F2550-E542 S26361-F2550-E543 S26361-F2550-E544 S26361-F2550-E545
Main memory 512MB Main memory 1024MB Main memory 2048MB Main memory 4096MB
PC1600 registered DDR RAM PC1600 registered DDR RAM PC1600 registered DDR RAM PC1600 registered DDR RAM
4x
consisting of 4 modules consisting of 4 modules consisting of 4 modules consisting of 4 modules
occupies one bank occupies one bank occupies one bank occupies one bank
max. 4x per system max. 4x per system max. 4x per system max. 4x per system
Section IV Graphics
B
Fujitsu Siemens Computers
Enterprise Products - PRIMERGY Server 6 of 12
