7. CUSTOMIZING YOUR UNIT
7-16
CHART CONFIGURATION menu description
CHART CONFIGURATION menu description
Object Content Settings Description
ON Turns perspective display on. PERSPECTIVE Perspective
display on/off OFF Turns perspective display off.
ON Removes overlapping objects from
display. DE-CLUTTER Overlapping
object on/off
OFF Displays overlapping objects.
FULL All chart attributes are displayed.
SIMPLE Some attributes such as SEABED
TYPE, TRACKS and ROUTES are
displayed.
FISHING Setting for use in fishing.
LOW Only NAV AIDS and water depth are
shown.
CHART
DISPLAY MODE Choose chart
display mode
CUSTOM User chooses which chart attributes to
turn on or off.
ON Safety status ON (See Safety Status
Indication on page 7-18 for
description.) SAFETY
STATUS*
1
Safety status
indication
OFF Safety status OFF
PLOT/OVERLAY Shown on plotter and overlay
displays.
PLOT Shown on plotter display.
WAYPOINT Waypoints marks
and waypoint
names
OFF Waypoint markers and waypoint
names are turned off. Waypoint
names are not displayed regardless if
WAYPOINT NAME (below) is set to
ON.
PLOTTER/OVER
LAY Shown on plotter and overlay
displays.
PLOT Shown on plotter display.
WAYPOINT
NAME Waypoint names
OFF Waypoint names are turned off.
PLOTTER/OVER
LAY Shown on plotter and overlay
displays.
PLOT Shown on plotter display.
NAMES Text for land and
sea areas
OFF Names are turned off.
PLOTTEROVERL
AY Shown on plotter and overlay
displays.
PLOT Shown on plotter display.
BUOYS NAME Name of buoys
OFF Buoy names are turned off.
US NOAA symbols are shown.
US SIMPLE Complex object shown with single
icon.
INT International symbols are shown.
INT SIMPLE Complex object shown with single
icon.
PLOTTER/OVER
LAY Shown on plotter and overlay
displays.
PLOT Shown on plotter display.
NAV-AIDS Lighthouses,
buoys, etc.
OFF Navaids are turned off.
ON Light sectors displayed. LIGHT
SECTORS Light sector
FLASHING Light sectors displayed and flashing.
(Con’t on next page)
