Fluke 434 - Manual (Page 86)

Fluke 433/434
Users Manual
18-8
Measuring Function/
Screen Type
Measuring Data to be adjusted Settings Type
1. Scope Waveform Volt, Amp (separate for Phase
and Neutral) Range
2. Volts/Amps/Hertz Trend Volt (Peak), Amp (Peak), CF,
(separate for Phase and Neutral),
Hz Offset + Span
(2 screens)
3. Dips & Swells Trend
Volt, Amp (separate for Phase
and Neutral) Offset + Span
4. Harmonics Table Harmonics to be displayed, THD,
DC, V, A, W, V&A, %r (of rms) /
%f (of fundamental) Harmonic order
Trend Harmonics, THD, DC Offset + Span
5. Power & Energy Trend W, VA, VAR, PF, DPF/cos Φ,
Vrms, Arms (separate for Phase
and Neutral)
Offset + Span
(2 screens)
Demand Interval, kWh/pulse,
DPF/cos ϕ, FULL/FUNDamental
To customize measurements
6. Flicker Trend Pst, Plt, Dc, Dmax, Td<%, PF5 Offset + Span
Function D-parameter Settings Steady time, Steady Tolerance,
Threshold
7. Unbalance Trend Unbal V, Unbal A, V, A, Hz, ΦV-V,
ΦV-A (separate for Phase and
Neutral)
Offset + Span (2 screens)
8. Transients Waveform V, A (separate for Phase and
Neutral) Span
Function Trigger conditions V/A level + type of trigger
9. Inrush Trend A, V(separate for Phase and
Neutral) Offset + Span
Function Trigger conditions Current characteristics
10. Monitor Trend Vrms V, A (separate for Phase and
Neutral) (2 screens)
Offset + Span
Trend Harmonic Number Offset + Span
Flicker Trend Pst, Plt Offset + Span
Unbalance Trend Percentage Offset + Span
Frequency Trend Hz Offset + Span
Available function keys:
11 F1 - DEMO mode: the input sensitivities are increased to 2 V for use
with a demo generator. The generator is capable to generate 3-phase
voltages and currents with various interference types.
12 F4 - ALL DEFAULT: resets all settings in this menu to factory default.
13 F5 - BACK: return to SETUP entry menu.
