Fluke 433/434
Users Manual
21-12
Dips and Swells
Item Specification
Resolution 25ms, 50ms, 100ms, 200ms, 500ms, 1s, ... , 450d
Duration 90s, 180s, 6m, 12m, 30m
Memory 3600 min, max, and avg. points for each reading
Inrush mode
Item Specification
Resolution 25ms, 50ms, 100ms, 200ms, 500ms
Duration 90s, 180s, 6m, 12m, 30m
Memory 3600 min, max, and avg. points for each reading
Wiring Combinations
Abbreviation on Configuration Screen Description
1Ø + NEUTRAL Single Phase with Neutral
1Ø IT NO NEUTRAL Single Phase IT without Neutral
2Ø Split Phase Split Phase with Neutral
3Ø WYE 3-Phase Wye with Neutral
3Ø IT 3-Phase Wye IT without Neutral
3Ø DELTA 3-Phase Delta
3Ø HIGH LEG 3-Phase Delta High Leg
3Ø OPEN LEG 3-Phase Delta Open Leg
