Server Features
5
Cooling
T5120:
Four hot-swappable fan modules (two fans per module)
T5220:
Three hot-swappable fan modules (two fans per module)
Ethernet Ports
Four 10/100/1000 Mbps Ethernet, RJ-45-based, autonegotiating ports
(on two separate controllers)
Note -
10-Gb Ethernet ports are available by adding XAUI cards
PCI Express Interfaces
T5120:
Three standard half-length, half-height PCI Express slots with the
following slot designated specifications
†
:
• One slot—PCIe, 8-lane
• Two slots—PCIe 4-lane (alternatively, these slots can be used for 10
Gb Ethernet by adding XAUI cards)
T5220:
Six standard half-length, half-height PCI Express slots with the
following slot designated specifications
:
• Two slots—PCIe, 8-lane
• Two slots—PCIe, 4-lane
• Two slots—PCIe 4-lane (alternatively, these slots can be used for 10
Gb Ethernet by adding XAUI cards)
Note -
All PCIe cards are installed using supplied riser boards
USB Ports
Four USB 2.0 ports (2 forward, 2 rear facing)
Additional Ports
The following connectors are located on the rear of the server:
• One RJ-45 serial management port (SER MGT)—the default
connection to system controller
• One 10/100 Mbps Ethernet network management port (NET
MGT)—connection to the system controller
• One DB-9 serial port—connection to the host
Remote Management
On-board Integrated Lights Out Manager (ILOM) system controller,
with two command sets:
• ILOM
• ALOM CMT (legacy command set)
TABLE 1
Feature Specification Table (Continued)
Feature
Specifications
