– 146 –
Chapter 8 System Menu — System settings
[On]
f When [BKGD] is selected as the type of the ancillary data for corresponding DSKPGM output
Superimposes the ancillary data of the PGM output from ME that will become the base.
f When [DSK1] to [DSK4] is selected as the type of the ancillary data for corresponding DSKPGM output
Superimposes the ancillary data of the source selected in the key file bus for DSK1 to DSK4.
[AUTO]
f When [BKGD] is selected as the type of the ancillary data for corresponding DSKPGM output
Superimposes the ancillary data of the PGM output from ME that will become the base.
f When [DSK1] to [DSK4] is selected as the type of the ancillary data for corresponding DSKPGM output
- During the period that the DSK1 to DSK4 are turned on
Superimposes the ancillary data of the source selected in the key file bus for DSK1 to DSK4.
- During the period that the DSK1 to DSK4 are not turned on
Does not superimpose the ancillary data.
f For selecting the type of ancillary data for the corresponding DSKPGM output, refer to Step 6 .
6
Select an item in [DSKPGM1]/[DSKPGM2] in the [DSK ANC TYPE] column.
f Selects the type of the ancillary data to superimpose to the DSKPGM output (DSKPGM1/DSKPGM2).
f Selects the type for DSKPGM1 output in [DSKPGM1], and the type for DSKPGM2 output in [DSKPGM2].
[BKGD] The ancillary data for PGM output of ME to be the base.
[DSK1] The ancillary data for the source selected in the key file bus of DSK1.
[DSK2] The ancillary data for the source selected in the key file bus of DSK2.
[DSK3] The ancillary data for the source selected in the key file bus of DSK3.
[DSK4] The ancillary data for the source selected in the key file bus of DSK4.
7
Select an item in [ME ANC Mode] in the [ME ANC Mode] column.
f Selects if all ME to apply the same setting or to apply individual setting for each ME as the type of the ancillary data for ME.
[Common]
f The same setting is applied to all ME.
Setting in the [ME ANC Mode] column
→ [Common] is applied.
[Each]
f The individual setting is applied for each ME.
Setting in the [ME ANC Each Type] column
→ [ME1], [ME2] item is applied respectively.
8
Select an item in [Common] in the [ME ANC Mode] column, and [ME1] and [ME2] in the [ME ANC Each Type] column.
Selects the type of the ancillary data to be superimposed to the ME1PGM output, ME2PGM output, ME1PVW output, and ME2PVW output.
[BKGD] Ancillary data of the source selected in the PGM bus or the PST bus of each ME
[KEY1] Ancillary data of the source selected in the KEY1 fill bus of each ME
[KEY2] Ancillary data of the source selected in the KEY2 fill bus of each ME
[KEY3] Ancillary data of the source selected in the KEY3 fill bus of each ME
[KEY4] Ancillary data of the source selected in the KEY4 fill bus of each ME
Setting the ancillary for the MultiView display
1
Select the button → [SYSTEM] → [Video] tab.
2
Select an item in [MV1] to [MV4] in the [MV Ancillary] column.
f Configure the setting to superimpose the ancillary data to each MultiView display output.
[ME1‑PGM]/[ME2‑PGM] Superimposes the ancillary data of the source selected in the PGM bus of ME1/PGM bus of ME2.
[ME1‑PVW]/[ME2‑PVW] Superimposes the ancillary data of the source selected in the PST bus of ME1/PST bus of ME2.
[DSK‑PGM1]/[DSK‑PGM2] Superimposes the ancillary data superimposed to DSKPGM1/DSKPGM2.
[Off] Does not superimpose the ancillary data.
Setting the crosspoint switching
The timing at which the crosspoints are to be switched can be set.
f This switching involves the operation of the crosspoint buttons and the button.
1
Select the button → [SYSTEM] → [Video] tab.
2
Select an item in [Timing] in the [XPT Switch] column.
f Select the timing of switching.
[Any] The crosspoints are switched in the nearest field. This is for live applications.
[Field1] The crosspoints are switched in field 1. This is for editing applications.
[Field2] The crosspoints are switched in field 2. This is for editing applications.
Network settings
For details on network settings, refer to “Network settings” (page 47).
