Chapter 5: Motion setup
UltraView IP PTZ 36X Camera User Manual 47
Figure 20: Shadow tour (pattern) screen
Table 9: Shadow tour menu description
Parameter Description
Patterns Displays the selected shadow tour number.
Space Remaining memory available to record a shadow tour.
Record start Start recording the selected shadow tour.
Record stop Stop recording the selected shadow tour.
Record clear Deletes the selected shadow tour.
Preview Previews the tour to check that it is as desired.
Stop Stop the preview.
Note: The m otion limit stop function is unavailable when configuring and
replaying shadow tours.
To set up a shadow tour:
1. In the Motion folder, click the Pattern subfolder to open its screen.
2. Enter the shadow tour number. The amount of memory available to record the
shadow tour is displayed.
3. Click Record Start and use the PTZ control buttons to record the route for
this shadow tour.
When the memory reaches zero, no further recording can be done.
