29
●
●
●
●
●
Chapter 4
Command Return or Error Codes
Commands always return the command word and command status. The command status
word may include the following codes:
return codes #Value description
SUCCESS 0.0 Pass
NOTALLOWED
-1.0
Bad state for command, tried to run to start
a cycle while refilling or trying to refill
while running a dispense/fill cycle.
OUTOFTOLERANCE -3.0 Out of tolerance
INDEXOUTOFRANGE -4.0 Out of Range
NOSUCHCMD -5.0 Command bad
C2FAILNODEVS -6.0 No C2 devices
C2FAILCAPEQ -7.0 Failure, C2 capacities not equal
HARDCALFAILCOUNTS
-8.0
Fails, too few ADC counts between high -
low
NOSUCHPARAM -9.0 Parameter ID incorrect
Second and Third Words - 1, 2: Parameter Number and Value
The second and third words in the output table, Parameter Number and Parameter Value,
are used by the WRITEPARAM command. For details see the Parameter Table below.
Expanded descriptions are listed below the table by parameter number.
Notes When set by a command, all parameters are saved to non-volatile memory. The scale
calibrations are saved automatically when completed successfully
DINT Configuration Parameters
Parameter
Name Parameter
Number Parameter
Default Description
Channel Active 1.0 1 Boolean, 1 = ON, 0 = OFF
Weight Units 2.0 3
Value Frequency (Hz)
0 Pounds(lb)
1 Ounces(oz)
2 Ton(ton) short ton
3 Kilograms(kg)
4 Grams(g)
5 Metric Tonnes (t) long ton
NumAverages 3.0 10 1 -255
Averages the current sample and previous
N samples to provide the current weight
value.
