26
●
●
●
●
●
Chapter 4
Default output table formats
Output table
offset Content
0 Command
1 Parameter Number (used by read and write commands)
2 Parameter Value (used by write command and set relay command)
3 *spare*
4
5
6
7
Output Assembly for Weigh Scale 1
Output table
offset Content
8 Command
9 Parameter Number (used by read and write commands)
10 Parameter Value (used by write command and set relay command)
11 *spare*
12
13
14
15
Output Assembly for Weigh Scale 2 (for HI 1756 2DF only)
Commands to the PLC related to weigh scale 2, input table offset 8 – 15, are only valid
for HI 1756 2DF modules. For the HI 1756 1DF modules this portion of the input table
will be set and held in its default NOCMD state.
