Display Panel
Operations such as running a test and prewarming a well can be carried out simultaneously on both wells.
However, commands, prompts, and test results that appear on the display panel apply to a single well. The
well for which commands are displayed is designated by the position of the divider bar (the bar in which
the time and remaining battery power are displayed) (Figure 3).
Figure 3. Display Panel
Commands and results for Well 1 are shown in the upper portion of the of the display panel, while
commands and results for Well 2 are shown in the lower portion of the display panel (Figure 4).
Figure 4. Display of Commands
Press the appropriate MENU key to display a menu of commands for the corresponding well. Press the
appropriate START key to start a test in the corresponding well. During testing and other operations, the
divider bar indicates the well for which results or prompts are displayed (Figure 5).
Figure 5. Display of Results
Well 1
Commands
Divider Bar
Divider Bar
Well 2
Commands
Well 1 Test
Results and
Prompts
Divider Bar
Divider Bar
Well 2 Test
Results and
Prompts
Divider Bar
Arrows
