Configure/Display Valid ID List

Command

Description

Add new Device ID or Status Code to Valid ID list; valid numbers = 0 thru 255 (Note: Valid

ID list must have a minimum of one entry)

Delete a Device ID or Status Code to Valid ID list; valid numbers = 0 thru 255 (Note: Valid

ID list must have a minimum of one entry)

34c

Set Valid ID list to default values; i.e. V5 Activator IDs and Status Codes (default)

37c

Clear Valid ID list; i.e. delete all IDs/Codes from 000 to 255 except 127 (Note: List cannot

be empty)

38c

Return and display current configuration information; i.e. Device ID, Valid ID list, and

configuration settings/values

Configure/Activate TTL Output Control

Command

Description

10c

Turn on TTL output 1 now

11c

Turn on TTL output 2 now

13c

Set TT: output 1 alarm flag to OFF; i.e. do not turn on TTL output 1 if Status Code =

000 (default)

27c

Set TTL output 1 alarm flag to ON; i.e. turn on TTL output 1 if Status Code = 000

14c

Set TTL output 2 alarm flag to OFF; i.e. do not turn on TTL output 2 if Status Code =

000 (default)

28c

Set TTL output 2 alarm flag to ON; i.e. turn on TTL output 2 if Status Code = 000

16c

Set TTL output 1 valid read flag to OFF; i.e. do not turn on TTL output 1 on valid tag

read (default)

30c

Set TTL output 1 valid read flag to ON; i.e. turn on TTL output 1 on valid tag read (per the

Valid ID list)

17c

Set TTL output 2 valid read flag to OFF; i.e. do not turn on TTL output 2 on valid tag

read (default)

31c

Set TTL output 2 valid read flag to ON; i.e. turn on TTL output 2 on valid tag read (per the

Valid ID list)

D Set control TTL output 1 signal duration time in seconds; valid numbers = 0 thru

255 (default = 5 seconds)

E Set control TTL output 2 signal duration time in seconds; valid numbers = 0 thru

255 (default = 5 seconds)

Receiver Command Responses

The response to a command will be either a two-digit response code or the specific

information requested by a query command. Due to the limited processing capability of the

Receiver, the application software (E-OLS, ActiveTrac) or Third Party manages the process

as follows:

(a) buffers all outgoing commands;

(b) sends commands one at a time (minimum 100 ms delay between commands);

(d) resends commands if no response is received within a specified time-out period.
