Network Receiver
30 750.001.005 R04 © 2005 AXCESS Inc.
Network Receiver Installation
Once the Network Receiver has been configured with the following:
• An IP Address
• A Subnet Mask
• Users and a Password
The unit can be installed at its final location in accordance with the
instructions in this section of the manual. Exception: For network
operation, the only connections required to the receiver are: Power
(9 VDC adapter supplied – see note on page 11) and a Category-V
cable connection to the site network or Internet. The Network
Receiver requires a cable with RJ-45 connectors for network hookup.
After the Network Receiver has been configured and installed, refer to
“Connecting to a Device” in the ActiveTrac TM User Guide (Doc.
#750.008.005) – or, the manual for a third party device if applicable.
Connecting to a Wiegand Control Panel
Connecting to a Wiegand control panel requires black, white and
green wire of sufficient length to connect the Network Receiver to the
Wiegand control panel. With 22-gauge wire, 200 feet of wire can be
run. With 18-gauge, 500 feet can be run.
To connect the Network Receiver to a Wiegand control panel
1. Install the Wiegand control panel according to the instructions
provided with that unit.
2. Connect the Ground, Data One and Data Zero wires to the back
panel of the Network Receiver (Figure 15). Ensure the
termination is secure, but not over-tight.
TIP Each Network Receiver is shipped with a parts box that contains the
termination blocks. These termination blocks can be removed from the
Receiver for ease of wiring .
