© 2002, AXCESS Inc. 750.001.005 R0000 15
Setting Up a Wiegand System
Responding to Activator IDs
By default, the Receiver will only output Wiegand data from
Tags activated by Activator ID 127 . Use the following
commands to modify the way the Receiver responds to
Activator IDs.
Command Action
W Change Activator ID
(This is known as the Wiegand ID. The default is to
only output reads corresponding with this Activator)
33c Respond to multiple Activator IDs
(Wiegand output of the Receiver will now include all
tag reads from Activators listed as valid Activator IDs
for serial output in addition to the Wiegand ID)
19c Disable multiple Activator IDs
(Returns the Wiegand output to the single Wiegand
Activator ID)
Alarm Output
By default, the Network Receiver does not output Tag data
containing alarm codes from Panic and Tamper Tags via the
Wiegand port. Use the following commands to enable or
disable alarm data output.
Command Alarm
26c Enable output Tag data containing alarm codes
from Panic or Tamper Tags
(By default, the Receiver does not output alarm data)
12c Disable alarm data output (Default)
Setting Up a Serial or LAN System
Setting the Baud Rate
The following commands are available for configuring the
Network Receiver’s serial port:
Command Action
23c Set baud rate to 4800
24c Set baud rate to 9600
25c Set baud rate to 19,200 (default)
