Network Receiver
28 750.001.005 R04 © 2005 AXCESS Inc.
Figure 14 Select the com port to which the receiver is connected
8. Enter the following information in the Com Properties
dialog box; then click OK:
Baud Rate 115200
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
9. Press Enter on the PC keyboard to get a login prompt. It
may be necessary to press Enter several times to receive
the login prompt .
10. Continue as described in items 7 through 13 under
instructions for using a Crossover cable to connect to the
network.
