Connecting to a Network via Crossover Cable
Connecting to the Network via Crossover cable (included) will
typically be the simplest method of connecting the Network
Receiver.
To connect via Crossover cable
1. On the desktop, right-click on the Network Neighborhood
icon and select Properties . The Network dialog box will
appear (Figure 6).
2. Select TCP/IP (network, e.g. Ethernet, etc.) from the list
and click Properties .
Figure 6 Select TCP/IP from the list
3. Write down the original IP address that appears in the
TCP/IP Properties dialog box (Figure 7).
IMPORTANT! Note all previous settings as it will be necessary
to reset your PC after the Network Receiver is configured.
4. Click on the Specify an IP Address option button and enter
192.168.1.199 as the IP address and 255.255.255.0 the
subnet mask .
