Stereo Audio Codec
with FLEXSOUND Technology
MAX98088
75
Figure 15. Digital Audio Signal Routing
Table 9. Common Digital Audio Formats
X = Don’t care.
data input to either SDINS1 or SDINS2 to be routed
from one interface to the other for output on SDOUTS2
or SDOUTS1. Both interfaces must be configured for
the same sample rate, but the interface format need
not be the same. This allows the IC to route audio data
from one device to another, converting the data format
as needed. Figure 15 shows the available digital signal
routing options.
MODE
WCI1/WCI2
BCI1/BCI2
DLY1/DLY2
TDM1/TDM2
SLOTL1/SLOTL2 SLOTR1/SLOTR2
Left Justified
Set as desired
Set as desired
0
0
X
X
I
2
S
1
0
1
0
X
X
PCM
X
1
X
1
0
0
TDM
X
1
X
1
Set as desired
MAS1
DAI1
DAI1
RECORD PATH
DAI1
PLAYBACK PATH
DAI2
PLAYBACK PATH
SEL1
SEL2
BCLK1
BCLKS1
LRCLK1
SDOUT1
SDIN1
LTEN1
LBEN1
+
BIT
CLOCK
FRAME
CLOCK
DATA
OUTPUT
DATA
INPUT
MAS1
HIZOFF1
SDOEN1
SDIEN1
SDIEN2
MAS2
DAI2
BCLK2
LRCLK2
SDOUT2
SDIN2
BIT
CLOCK
FRAME
CLOCK
DATA
OUTPUT
DATA
INPUT
MAS2
HIZOFF2
SDOEN2
LRCLKS1
SDOUTS1
SDINS1
DVDDS1 BCLKS2
LRCLKS2
SDOUTS2
SDINS2
DVDDS2
MUX
LBEN2
