Stereo Audio Codec
with FLEXSOUND Technology
MAX98088
62
Table 1. Register Map (continued)
REGISTER B7 B6 B5 B4 B3 B2 B1 B0 ADDRESS DEFAULT R/W PAGE
EQ Band 5
(DAI1/DAI2)
K_5[15:8] 0x7A/0xAC 0xXX R/W 89
K_5[7:0] 0x7B/0xAD 0xXX R/W 89
K1_5[15:8] 0x7C/0xAE 0xXX R/W 89
K1_5[7:0] 0x7D/0xAF 0xXX R/W 89
K2_5[15:8] 0x7E/0xB0 0xXX R/W 89
K2_5[7:0] 0x7F/0xB1 0xXX R/W 89
c1_5[15:8] 0x80/0xB2 0xXX R/W 89
c1_5[7:0] 0x81/0xB3 0xXX R/W 89
c2_5[15:8] 0x82/0xB4 0xXX R/W 89
c2_5[7:0] 0x83/0xB5 0xXX R/W 89
Excursion
Limiter
Biquad
(DAI1/DAI2)
a1[15:8] 0xB6/0xC0 0xXX R/W 89
a1[7:0] 0xB7/0xC1 0xXX R/W 89
a2[15:8] 0xB8/0xC2 0xXX R/W 89
a2[7:0] 0xB9/0xC3 0xXX R/W 89
b0[15:8] 0xBA/0xC4 0xXX R/W 89
b0[7:0] 0xBB/0xC5 0xXX R/W 89
b1[15:8] 0xBC/0xC6 0xXX R/W 89
b1[7:0] 0xBD/0xC7 0xXX R/W 89
b2[15:8] 0xBE/0xC8 0xXX R/W 89
b2[7:0] 0xBF/0xC9 0xXX R/W 89
REVISION ID
Rev ID
REV 0xFF 0x40 R 112
