Chapter 8
PFI
© National Instruments Corporation
8-3
Exporting Timing Output Signals Using PFI Terminals
You can route any of the following timing signals to any PFI <6..9>
terminal.
•
AI Convert Clock*
•
AI Hold Complete Event
•
AI Reference Trigger
•
AI Sample Clock
•
AI Start Trigger
•
AO Sample Clock*
•
AO Start Trigger
•
Counter n Source
•
Counter n Gate
•
Counter n Internal Output
•
Frequency Output
•
PXI_STAR
•
RTSI <0..7>
Note Signals with a * are inverted before being driven to a terminal.
Using PFI Terminals as Static Digital Inputs and Outputs
When a terminal is used as a static digital input or output, it is called P0.x
or P1.x. On the I/O connector, each terminal is labeled PFI x/P0.x or
PFI x/P1.x.
Connecting PFI Input Signals
All PFI input connections are referenced to D GND. Figure 8-3 shows this
reference, and how to connect an external PFI 0 source and an external
PFI 2 source to two PFI terminals.
