298 IBM 9077 SP Switch Router: Get Connected to the SP Switch
C.4 Connectors and Receptacles for Different Media
Table 55 gives you a comprehensive overview of all the supported cables and
connectors for the various media cards.
Table 55. Media Card Cables and Connectors
C.5 Chip Interconnection on the TBS Board
Figure 73 on page 299 is taken from the Redbook RS/6000 SP: Problem
Determination Guide, SG24-4778-00, Chapter 4.2 "Reviewing Switch
Boards".
Media Card Cable Support Connector
SP Switch SP Switch Cable (5, 10, 15, 20m) 2-row, 50-pin
shielded tab
connector
ATM OC-3c Multimode Two 62.5/125 micron
fiber optic cables Duplex SC
transceiver
ATM OC-3c Singlemode Two 9/125 micron
fiber optic cables Duplex SC
transceiver
ATM OC-12c Multimode One 62.5/125 micron
fiber optic cables Duplex SC
transceiver
ATM OC-12c Singlemode One 9/125 micron
fiber optic cables Duplex SC
transceiver
10/100 Base T Four/Eight STP or UTP CAT5
cable RJ 45
FDDI Four mulitmode cables
(62.5/125 micron) MIC transceiver
HIPPI Two twisted-pair copper cable
HSSI Two 25 twisted-pair
shielded coax cables 2-row, 50-pin
receptacle
heads
IP/SONET OC-3c Singlemode One 9/125 micron
fiber optic cables Duplex SC
transceiver
IP/SONET OC-3c Multimode One 62.5/125 micron
fiber optic cables Duplex SC
transceiver
