SCOM-100, User guide
34
8.3 Technical specifications
8.3.1 Main unit
Protection IP20
Temperature range
-10°C, +70°C, operating
Dimensions
106 x 90 x 58 mm
Weight 0.3
kg
LED indications
4 digital input LED, 4 digital output LED
6 control LED
Mounting
EN 60 715 TH35 DIN rails
Supply voltage
SCOM-100-MU-12 : 12VDC+/-10%
SCOM-100-MU-24 : 24VDC+/-10%
Supply current
rated 250 mA max, (2 A burst)
Analog inputs
2, resolution 10 bit
Digital inputs
4, pull, GND to Vcc
Digital outputs
4, relay, 250V, 10A AC1
Baud rate: 2400 to 115200 bps
Serial port (COM2)
Protocols: Hayes AT, Custom AT (atsms)
SIM Card : SIM card holder
RS232C: RJ-45 connector
I/O expansion: 6 pin modular connector
Microphone: 2 pin array connector
Interfaces
Power supply & I/O: screw terminals
GSM MODEM
Quad Band (850/900/1800/1900MHz)
SMS
GSM Text Format
8.3.2 GE-DIO-42 Digital I/O Expansion module
Protection IP20
Temperature range
-10°C, +70°C, operating
Dimensions
53 x 90 x 58 mm
Mounting
EN 60 715 TH35 DIN rails
Supply voltage
GE-DIO-42-12 : 12VDC+/-10%
GE-DIO-42-24 : 24VDC+/-10%
Supply current
80 mA max
Digital inputs
4, pull, GND to Vcc
Digital outputs
2, relay, 250V, 10A AC1
Interfaces
I/O expansion: 2 x 6 pin modular connector
