79 - Device Ports

Headphone/Line-Out Jack

The headphone/line-out jack allows you to connect headphones or powered external speakers to your
notebook. (See Figure 3 for location.) Your headphones or speakers must be equipped with a 1/8” (3.5
mm) stereo mini-plug. In order to connect headphones or speakers follow these easy steps:

1

Align the connector with the port opening.

2

Push the connector into the port until it is seated.

Microphone/Line-In Jack

The microphone/line-in jack allows you to connect an external mono microphone. (See Figure 3 for
location.) Your microphone must be equipped with a 1/8”(3.5 mm) mono mini-plug in order to fit into the
microphone jack of your notebook. In order to connect a microphone follow these easy steps:

1

Align the connector with the port opening.

2

Push the connector into the port until it is seated.

External Video Port

The external video port allows you to connect an external monitor or LCD projector. (See Figure 5 for
location.) In order to connect an external video device, follow these easy steps:

1

Align the connector with the port opening.

2

Push the connector into the port until it is seated.

3

Tighten the two hold-down screws, located on each end of the connector.

I

F

YOU

PLUG

HEADPHONES

INTO

THE

HEADPHONE

JACK

,

BUILT

-

IN

STEREO

SPEAKERS

WILL

BE

DISABLED

.

P

RESSING

THE

[F

N

] + [F10]

KEYS

ALLOWS

YOU

TO

CHANGE

YOUR

SELECTION

OF

WHERE

TO

SEND

YOUR

DISPLAY

VIDEO

. E

ACH

TIME

YOU

PRESS

THE

KEY

COMBINATION

,

YOU

WILL

STEP

TO

THE

NEXT

CHOICE

,

STARTING

WITH

THE

BUILT

-

IN

DISPLAY

PANEL

ONLY

,

MOVING

TO

THE

EXTERNAL

MONITOR

ONLY

,

FINALLY

MOVING

TO

BOTH

THE

BUILT

-

IN

DISPLAY

PANEL

AND

AN

EXTERNAL

MONITOR

.
