Page 24
19 - Locating the Controls and Connectors
Figure 6. LifeBook notebook bottom panel
Bottom Components
The following is a brief description of your LifeBook notebook’s bottom panel components.
Docking Port Connector
This connector allows you to connect the optional Port Replicator.
Air Vents
The air vents allow air to circulate through the system to cool down the components.
Docking Port Connector
Air Vents
Memory
Upgrade
Compartment
Hard Disk Drive Cover
Lithium ion Battery Pack
Main Unit and
Configuration Label
(approximate location)
Battery Pack Latches
