Hubbell LX-440 - Manual (Page 16)

Transfer Switch
Page 16 of 16 Pages
9.0 Spare Parts and Drawing References
The following lists contain part numbers and drawing numbers for identification and for ordering. If
materials are needed from Hubbell, contact the local Hubbell representative to request the desired
information or parts.
Spare Parts
Description Part No.
Spares
2 Years
Description Part No.
Spares
2 Years
Transformer
100 VA
200 VA
57511355
57511343 1
1
Phase Rotation Monitor
208–260 V
440–480 V
57418-398
57418-399 1
Socket 402066520
Lens, red 402067520
Lens, green 402066720
LX-450 TCR Board
w/o Timer, w/ Switch
w/ Timer, w/ Switch
w/o Timer, w/ Switch
w/ Timer, w/ Switch
49271-101
49271-102
49271-104
49271-105
1
120 V Bulb 80324905 2
Black Push Button 80320400 AR relay, 2 pole 31658-123 1
12 point terminal strip 57520323 AR1 relay, 3 pole 31658-112 1
Plant Exerciser, SPDT 31658139
LX-301 Control Modules
Standard Standard
200 V/3 pole/60 Hz 90363-001 240 V/3 pole/60 Hz 90363-005
208 V/3 pole/60 Hz 90363-002 440 V/3 pole/60 Hz 90363-006
220 V/3 pole/60 Hz 90363-003 460 V/3 pole/60 Hz 90363-007
230 V/3 pole/60 Hz 90363-004 480 V/3 pole/60 Hz 90363-008
Engine Start Relay, 12 VDC 31658-076 1
Drawing References
Drawing No. Title Drawing No. Title
49271-500 Schematic
Transfer Control Relay Board
Notes
As built schematics and wiring diagrams are provided as part of the drawing packet supplied with each
transfer switch.
Refer to Bulletin 1000 for information about one year parts and labor warranty.
