English 33
2 How to Install Accessories In Your PC
Installing Mass Storage Devices
8 Support the power supply with your hand and very carefully return
the PC to the upright position.
9 Connect the data and power cables to the rear of the drive.
The connectors are shaped to fit one way only. If you are not sure
which connector to use, refer to "Connecting IDE Devices", on page
28.
10 Replace the CD-ROM in the middle shelf.
11 Install any other accessories before replacing the power supply and
the cover. Replace the side bezel. Reconnect all cables and power
cords.
12 Verify the new configuration by checking the HP Summary Screen.
Refer to page 66.
Installing a Tape Drive in the Bottom Shelf
A tape drive can be installed in the bottom shelf.
1 Disconnect the computer’s power supply cord from the power outlet,
and disconnect the PC from any telecommunications network.
2 Remove the computer’s cover.
3 Remove the CD-ROM from the middle shelf.
Power cable Data cable
