HP xw8200 - Manual (Page 8)

Operating System
(choice) Microsoft Windows XP Professional SP2
Microsoft Windows XP Professional x64 Edition
OR HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions on HP xw9300,
xw8200, xw6200 and xw4200 Workstations)
Form factor Minitower
Color Carbonite/Alloy metallic
System Board Form
Factor E- ATX (12" x 13")
Processor Single or dual 64-bit Intel Xeon processors (Nocona) with Hyper-Threading Technology
CPU Bus Speed
Supported 800 MHz FSB
Standard L2 Cache 1 MB L2 cache (non ECC) or 2 MB L2 cache
Chipset Intel Tumwater
Memory Expansion Slots 8 DIMMs
Memory Type Supported DDR2 (ECC registered)
Memory Speed
Supported
DDR2 Synch DRAM PC2-3200 (400 MHz) Registered ECC
Maximum Memory 16 GB (8 DIMMs slots with 2 GB DIMMS)
Network controller Integrated Intel Pro MT 10/100/1000 LAN
Audio Integrated AC'97 digital audio with S/PDIF 6-channel pass-through, stereo microphone, and
Yamaha XG Lite Softsynth support
PCI slots 2 full-length PCI slots (3 full-height PCI-X slots (one 133 MHz, two 100 MHz slots)
1 PCI Express (x8 mechanically, x4 electrically)
1 PCI Express x16 graphics
AGP slot None
Bays Total Bays = 8
Internal Bays Five 3.5 inch bays (4 with acoustic dampening rail assemblies)
External Bays Three 5.25 inch full length 2003 mm maximum device depth (top bay is limited to 198 mm
depth when optional smart cover solenoid lock is installed. Bottom bay can be converted to
an internal 3.5" 3rd Hard Drive bay using optional bracket
Floppy drive bay using optional bracket
Parallel Port 1
Serial Port 1
Front I/O 2 USB 2.0, Headphone, Microphone, IEEE 1394
Rear I/O 1 IEEE-1394, 6 USB 2.0, 1 standard serial port, 1 parallel port, PS/2 keyboard and mouse, 1 RJ-
45 to integrated Gigabit LAN, Audio In, Audio Out, Mic In
USB Keyboard Optional
USB Mouse Optional
PS/2 Keyboard 1
PS/2 Mouse 1
Chassis Dimensions
(H x W x D) 17.9 x 8.3 x 20.7 in (45.4 x 21.0 x 52.5 cm)
System weight Minimum config – 42 lb (19 kg)
Standard config – 45 lb (20 kg)
Maximum config – 54 lb (24 kg)
Shipping weight Standard config – 54 lb (24 kg)
Temperature Operating 40° to 95° F (5° to 35° C)
Non-operating -40° to 140° F (-40° to 60° C)
Humidity Operating 8% to 85%
Non-operating 8% to 90%
Maximum Altitude
(nonpressurized) Operating 10,000 ft (3,000 m)
Non-operating 30,000 ft (9,100 m)
QuickSpecs
HP xw8200 Workstation
Standard Features - Specs
DA - 11976 Worldwide QuickSpecs — Version 42 — 5.25.2007 Page 8
