HP xw8200 - Manual (Page 68)

Self Powered USB 2.0
Hub One upstream, four downstream ports (cable
included)
Input Signal Two DVI-I connectors (dual VGA analog or
dual digital input possible)
Input Impedance 75 ohms ± 10%
Sync Input Separate sync (HSYNC/VSYNC); composite
sync, Sync on Green
Video Cable Two VGA to DVI-I; two DVI-D to DVI-I
Video Cable Length 5.9 ft (1.8 m)
Power Input Power Auto-Ranging, 90 to 132 VAC and 195 to 265
VAC; internal power supply, 50 Hz/60 Hz
Frequency 47.5 to 63 Hz
Typical Power
Consumption 55 watts (without USB ports); 70 watts (USB
ports fully loaded)
Maximum < 75 W
Power Saving < 2 watts
Power Cable Length 5.9 ft (1.8 m)
Mechanical Dimensions (H x W x D) Unpacked with stand 16.7 to 21.8 x 17.4 x
8.67 in
(42.5 to 55.5 x 44.3 x
22.0 cm)
Unpacked w/o stand
(head only) 13.58 x 17.4 x 3.42 in
(34.5 x 44.3 x 8.7 cm)
Packaged 11.77 x 22.2 x 16.77
in
(29.9 x 56.4 x 42.6
cm)
Weight Unpacked With stand: 20.28 lb
(9.2 kg);
Without stand: 12.35
lb (5.6 kg)
Packaged 26.3 lb (11.95 kg)
Tilt Range -5° to + 25° vertical tilt
Swivel Range -45° to + 45°
Height Adjustable Yes, range 5.1 in (13.0 cm)
Pivot Rotation Yes
Base Detachable, ships attached
Environmental Temperature –
Operating 46° to 95° F (10° to 35° C)
Temperature – Non-
operating 6° to 140° F (-10° to 60° C)
Humidity – Operating 20% to 80% non-condensing
Humidity – Non-
operating 5% to 85%
Altitude – Operating +12,000 ft (+3,657.6 m)
Altitude – Non-
operating +40,000 ft (+12,192 m)
Options HP Silver Flat Panel
Speaker Bar - Part
number: EE418AA Powered directly by the monitor or the PC, the
Speaker Bar seamlessly attaches to the
monitor's lower bezel to bring full audio
support to select HP flat panel monitors.
QuickSpecs
HP xw8200 Workstation
Technical Specifications - Monitors
DA - 11976 Worldwide QuickSpecs — Version 42 — 5.25.2007 Page 68
