Cooling
Cooling Solutions
Supported
Yes
Power Supply Fan 92 x 25 mm
Processor Fan-Heatsink 70 x 15 mm
Chassis Fan (front) One 92 x 25 mm (optional)
Chassis Fan (rear) One 120 mm x 28 mm (standard)
Internal Speaker Standard
Power Supply
Full Ranging Input Yes
Active Power Factor
Correction (APFC) (Input
Current is nearly ½ a
non-APFC PS) Yes
Passive Power Factor
Correction (PFC) No
Operating Voltage Range 90 – 264 VAC/118 VAC
Rated Voltage Range 100 – 240 VAC
Rated Line Frequency 50-60 Hz/400Hz
Operating Line
Frequency Range 47 – 66 Hz/393 – 407Hz
Rated Input Current 10A/8.6A
Maximum Rated Power 600 W
Heat Dissipation Typical 1206.2 btu/hr
Maximum 2047.4 btu/hr
PS Size (wide x high x
deep) 92mm variable speed
Energy Star Compliant Yes
Surge Tolerant Full
Ranging Power Supply Withstands power surges up to 2000V
Typical configuration
power consumption 2 processors (2x3.6GHz Xeon), 1 GB memory (2x512 MB)
Two hard drives (2xSATA 40 GB), DVD-ROM drive
PCI-Express Graphics Card (FX 1300)
Floppy, Monitor
Input Power consumption @ 120Vac/60Hz
Typical operating mode
(system busy)
353.5W = 1206.2 btu/hr
Windows XP Idle 210.3 W = 717.6 btu/hr
Hibernate mode (S4) 5.9 W = 20.1 btu/hr
Power Off (S5) 5.9 W = 20.1 btu/hr
ROM Features Description
Instantly Available PC Allows for very low power consumption with quick resume time
ROM Based F10 Setup
and diagnostics Review and customize BIOS settings
Remote System
Installation via F12 (PXE)
(Remote Boot from
Server) Allows a new or existing system to boot over the network and download software, including the
operating system
QuickSpecs
HP xw8200 Workstation
Technical Specifications
DA - 11976 Worldwide QuickSpecs — Version 42 — 5.25.2007 Page 19
