HP 2-button Optical
Scroll Mouse (USB)
Dimensions (H x L x W) 1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm)
Weight
0.27 lb (0.12 kg)
Cable length
72.8 in (185 cm)
System requirements
Microsoft Windows XP Professional, Microsoft Windows XP
Professional x64 Edition, Red Hat Enterprise Linux Workstation 3 and 4
Spaceball 5000 USB
(Windows XP only)
Physical
characteristics
Dimensions (H x W x D) 3.0 x 6.0 x 8.4 in (7.6 x 15.2 x 21.3 cm)
Ball Diameter
2.2 in (5.6 cm)
Weight
2.1 lb (9.94 kg)
Features
Six degrees of freedom motion control
through the X, Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC
applications
Environmental
Operating temperature 50° to 104° F (10° to 40° C)
Non-operating
temperature
43° to 140° F (6° to 60° C)
Operating humidity
8% to 80% (non-condensing at ambient)
Non-operating humidity5% to 80% (non-condensing at ambient)
Mechanical
Buttons
12 programmable (unshifted)
Ball Force Range
0.5 - 8.2N/1.8 - 29.5 oz
Ball Torque Range
0.085 – 0.33 oz-in. (6.91 Nmm)
Resolution
10 bits
Serial Specifications
Connector
USB 1.1 or greater
Cable Length
12.8 ft. (3.9 m)
Data Rate
USB model – 16 msec
Flow Control
Xon/Xoff (on PS/2 model only)
Software Drivers
Available
USB model
Microsoft Windows XP Professional
System Requirements Disk Space
10 MB free disk space
Regulatory Approvals
UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN
50082, IEC 1000 4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick
