System Unit
Dimensions (H x W x D)
(with bezel)
3.44x 17.64 x 27.50 in (8.75 x 44.80 x 69.88cm)
Weight
(approximate)
Maximum
(all hard drives, power
supplies and processors
installed)
51.5 lb (19.22 kg)
Minimum
(one hard drive, power
supply and processor
installed)
35.0 lb (13.06 kg)
Input
Requirements
(per power supply)
Rated Line Voltage
100 - 240 VAC
Rated Input Current
9.10 A (at 100 VAC),
4.5 A (at 200 VAC)
Rated Input Frequency 50 to 60 Hz
Rated Input Power
910 W (at 100 VAC),
900 W (at 200 VAC)
BTU Rating
Maximum
3107.82 BTU/hr (at 100 VAC),
3073.67 BTU/hr (at 200 VAC)
Power Specifications
To review typical system power ratings use the Power Calculator which
is available via the online tool located at URL:
Click on the system of interest. Example: DL180 G5
Follow the instructions of the next screens.
Power Supply Output
(per power supply)
Rated Steady-State
Power
750 W (at 100 VAC),
750 W (at 200 VAC)
Maximum Peak Power 750 W (at 100 VAC),
750W (at 200 VAC)
System Inlet
Temperature
Operating
50° to 95°F (10° to 35°C) at sea level with an
altitude derating of 1.8°F per every 1000 ft
(1.0°C per every 305 m) above sea level to a
maximum of 10,000 ft (3050 m), no direct
sustained sunlight. Maximum rate of change
is 18°F/hr (10°C/hr). The upper limit may be
limited by the type and number of options
installed.
System performance may be reduced if
operating with a fan fault or above 86°F
(30°C).
Non-operating
-22° to 140° F (-30° to 60° C). Maximum rate
of change is 36° F/hr (20° C/hr).
Relative Humidity
(non-condensing)
Operating
10 to 90% relative humidity (Rh), 82.4° F (28°
C) maximum wet bulb temperature, non-
condensing.
Non-operating
5 to 95% relative humidity (Rh), 101.7° F
(38.7° C) maximum wet bulb temperature,
non-condensing.
Altitude
Operating
10,000 ft (3050 m). This value may be limited
by the type and number of options installed.
Maximum allowable altitude change rate is
1500 ft/min (457 m/min).
