NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid
configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales
representative for information on CTO product offerings and requirements.
NOTE: HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Chassis.
NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE: FIO indicates that this option is a Factory Installable Option.
Step 1: Base Configuration (choose one of the following configurable models)
Hot Plug Models
HP ProLiant DL180 G5 Hot Plug SAS/SATA Rack CTO Chassis 457649-B21
Factory Integrated Model ships with:
One embedded NC105i PCI-E Gigabit Server Adapters (WOL & PXE-capable)
Three available PCI-Express slots:
Slot 1: x8 low-profile/half-height slot
Slot 2 & 3: x4 Full-Height/Full Length
NOTE: Optional PCI-X option kit includes: Slot 1 and 2: full-length/full-height
PCI-X 100. PCI-X slots are 64 bits; 133 MHz capable if only one PCI-X card is
installed in the server.
One HP SATA Embedded Cable Kit
750 Watt Power Supply
One Highline IEC Power Cord
4 Non-Hot Plug Fans
Rack (2U), (3.5 in/8.89 cm)
Step 2: Choose Required Options (only one of the following from each list unless
otherwise noted)
Processors Quad-Core Intel® Xeon® processor E5440 (2.83 GHz, 80 W, 1333 MHz FSB)
Kit, FIO
NOTE: If 2 processors are desired, select one 466106-L21 and one 466106-
B21.
466106-L21
Quad-Core Intel® Xeon® processor E5430 (2.66 GHz, 80 W, 1333 MHz FSB)
Kit, FIO
NOTE: If 2 processors are desired, select one 458784-L21 and one 458784-
B21.
458784-L21
Quad-Core Intel® Xeon® processor E5420 (2.50 GHz, 80 W, 1333 MHz FSB)
Kit, FIO
NOTE: If 2 processors are desired, select one 458785-L21 and one 458785-
B21.
458785-L21
Quad-Core Intel® Xeon® processor E5405 (2.00 GHz, 80 W, 1333 MHz FSB)
Kit, FIO
NOTE: If 2 processors are desired, select one 458786-L21 and one 458786-
B21.
458786-L21
Dual-Core Intel® Xeon® processor E5205 (1.86 GHz, 65W, 1066MHz FSB) Kit,
FIO
NOTE: If 2 processors are desired, select one 458787-L21 and one 458787-
B21.
458787-L21
Memory 1 GB PC2-5300 2 x 512 MB Single Rank Kit 408850-B21
1GB REG PC2-5300 1 x 1GB Kit 462483-B21
QuickSpecs
HP ProLiant DL180 G5
Configuration Information - Factory Integrated Models
DA - 12903 Worldwide QuickSpecs — Version 8 — 5.16.2008 Page 11
