HP ProLiant DL180 G - Manual (Page 27)

750W Power Supply
Spare Kit 451366-291, AA1, B21
Operational Input
Voltage Range (Vrms) 90Vac to 264Vac full range
Frequency Range
(Nominal) (Hz) 47 Hz to 63 Hz
Nominal Input Voltage
(Vrms) 100 115 200 220 230 240
Max Rated Output
Wattage Rating 750 750 750 750 750 750
Nominal Input Current
(A rms) 9.1 7.9 4.3 4.0 3.8 3.7
Max Rated Input
Wattage Rating (Watts) 893 888 872 862 862 862
Max. Rated VA
(Volt-Amp) 911 906 890 880 880 880
Efficiency (%) 84 84.5 86 87 87 87
Power Factor 0.98 0.98 0.98 0.98 0.98 0.98
Leakage Current (mA) <0.43 <0.50 <.0.90 <0.96 <1.00 <1.04
Maximum Inrush
Current (A peak) 30A 30A 30A 30A 30A 30A
Maximum Inrush
Current Duration (mS) 5mS 5mS 5mS 5mS 5mS 5mS
QuickSpecs
HP ProLiant DL180 G5
Power Specifications
DA - 12903 Worldwide QuickSpecs — Version 8 — 5.16.2008 Page 27
