CHAPTER 4
Fixture Programming
SHOWGUN ® User Manual 39
Control Settings
The Control parameter activates certain Fixture functions. To access all SHOWGUN ® Control
settings (except for Pan & Tilt MSpeed Off), first select a control channel value, then set the
Shutter channel to “0.”
NOTE: The Control channel should not be crossfaded.
DMX Control Setting Description
0-9 Safe Disables all Control settings for normal operation.
10-19
Pan & Tilt
MSpeed Off
Sets Pan & Tilt MSpeed to ignore MSpeed settings. The Control
channel should not be crossfaded.
20-28 Display Off Sets display to off.
Set Shutter parameter = 0
to access these control
options
40-48 Display Bright Brightens the display characters.
60-68 Home Remotely homes the fixture.
80-88 Lamp On Remotely restrikes the fixture’s lamp.
90-98 Lamp Off Remotely extinguishes the fixture’s lamp.
120-130 Shutdown
Remotely deactivates the fixture. When a fixture is shut down, the
lamp is extinguished, power to the motors is disabled, and the LED
display reads “
SHUT DOWN ”. If a fixture is in shutdown mode, you must
home the fixture to bring it back into operation.
131-140 Outrig Mode
Insures uninterrumpted movement of pan and tilt for fixtures side
mounted or in acute angular positions.
Note: Because this is a DMX mode, it will not persist in the fixture.
Side Mounting and Angular Mount by Moving Truss
To insure uninterrumpted movement of pan and tilt use "Outrig mode". Operating a fixture in the
Outrig mode will slow Pan and Tilt motion. Setting the Outrig mode in the Control parameter of
your DMX controller lets you turn the option on or off as needed during a production (when
trusses move to an accute angular position, for example).
Note: Because this is a DMX mode, it will not persist in the fixture.
