CHAPTER 3
SHOWGUN® Menu System
SHOWGUN ® User Manual 25
Pan Invert
This menu option inverts the direction of
the pan motor to coordinate movements
between fixtures mounted opposite each
other horizontally.
To invert the fixture’s Pan motion:
1. Press the Menu button to unlock the menu system or to move back up the system to the top
level menus.
2. Using the left and right arrows on the Center button, scroll through the top level to SET
PARAMETERS MENU and press the Enter button to select.
3. Using the left and right arrows on the Center button, scroll to PAN INVERT . The current state
( ENABLED or DISABLED ) will be displayed.
4. Use the up and down arrows on the Center button to scroll to ENABLED to invert Pan
movement or DISABLED to revert fixture to default setting and press the Enter button to
select.
Tilt Invert
This menu option inverts the direction of the tilt motor to coordinate movements
between fixtures on a link facing each other vertically.
To invert the fixture’s Tilt motion:
1. Press the Menu button to unlock the menu system or to move back up the
system to the top level menus.
2. Using the left and right arrows on the Center button, scroll through the top
level to SET PARAMETERS MENU and press the Enter button to select.
3. Using the left and right arrows on the Center button, scroll to TILT INVERT .
The current state ( ENABLED or DISABLED ) will be displayed.
4. Use the up and down arrows on the Center button to scroll to ENABLED to
invert Tilt movement or DISABLED to revert fixture to default setting and
press the Enter button to select.
