CHAPTER 3
SHOWGUN® Menu System
24 SHOWGUN ® User Manual
Set Parameters Menu
The Set Parameters menu sets all factory options to their default settings or changes the factory
options individually.
Factory Default Settings
A SHOWGUN fixture ships with the following factory default settings:
Pan Tilt Swap= DISABLED Tilt Invert= DISABLED Lamp Life Limit= DISABLED
Pan Invert= DISABLED Display Level= ON Data Loss Timeout= SHORT
If any of the default settings are changed, this menu reverts to the OFF option. The ON option
restores all factory defaults.
To check and reset factory defaults:
1. Press the Menu button to unlock the menu system or to move back up the system to the top
level menus.
2. Using the left and right arrows on the Center button, scroll through the top level to SET
PARAMETERS MENU and press the Enter button to select.
3. Using the left and right arrows on the Center button, scroll to FACTORY DEFAULT SETTINGS . The
current state ( ON or OFF ) will be displayed.
4. To reinstate the factory defaults if OFF is displayed, use the up and down arrows on the
Center button to scroll to ON and press the Enter button to select.
Pan/Tilt Swap
This option swaps the pan motor and tilt motor operation to
coordinate movements between fixtures on a link mounted
perpendicular to each other.
To swap Pan and Tilt:
1. Press the Menu button to unlock the menu system or to
move back up the system to the top level menus.
2. Using the left and right arrows on the Center button,
scroll through the top level to
SET PARAMETERS MENU and press the Enter button to
select.
3. Using the left and right arrows on the Center button,
scroll to PAN/TILT SWAP . The current state ( ENABLED or
DISABLED ) will be displayed.
4. Use the up and down arrows on the Center button to scroll to ENABLED to swap pan and tilt or
DISABLED to revert fixture to default setting and press the Enter button to select.
