1/99 SMV 3000 Transmitter User’s Manual 171
Appendix B

SMV 3000 Configuration Record Sheet
SMV 3000
Configuration Data
Sheets The following configuration sheets provide a means to record the SMV
3000 configuration database. You may want to fill it out prior to creating
the transmitter database file or before performing on-line configuration.
These sheets contain all of the configuration parameters for the SMV
3000. The default values are shown in bold.
SMV 3000 Model #: _________________________________________________
1. General Configuration Section
Tag I.D. Number: ____ ____ ____ ____ ____ ____ ____ ____
(8 Characters Max.)
Scratch Pad: _______________________________________________
(32 Characters Max.)
Mode of Operation: Analog ____ DE ____
Analog Output Choice: PV1 ___ PV2 ___ PV3 ___ PV4 ___
PV DE Mode Broadcast: PV1 On _____ PV1 On w/SV _____
(only required if selecting PV1 - PV2 On _____ PV1 - PV2 On w/SV1 _____
DE Mode of Operation) PV1 - PV3 On _____ PV1 - PV3 On w/SV1 _____
PV1 - PV4 On _____ PV1 - PV4 On w/SV1 _____
Line Filter: 50 Hz ___ 60 Hz ___
Failsafe Direction: Upscale _____ Downscale _____
(Analog Mode Only)
1a. Differential Pressure - PV1 - Configuration Section
PV1 Output Conformity: Linear ____ Square Root ____
PV1 Damping (sec.): 0.0 ___ 0.16 ___ 0.32 ___ 0.48 ___ 1 ___ 2 ___
4 ___ 8 ___ 16 ___ 32 ___
PV1 Eng. Units: "H2O_39F ___ PSI ___ MPa ___ bar ___
kg/cm^2 ___ mmH2O_4C ___ mmHg_0C ___ KPa ___
mbar ___ g/cm^2 ___ inHg_32F ___ ATM ___
mH2O_4C ___ "H2O_68F ___ "H2O_60F ___
PV1 Range: LRV _____ URV _____
(defaults are 0 and 100 inches H2O 39F)
Continued on next page
