HP NC512m Dual Port 10GbE Multifunction BL-c Adapter

NOTE:

NOTE:

NOTE:

NOTE: An NC512m network adapter card is required for each server blade
connecting to the HP 10Gb Ethernet BL-c Switch
NOTE:

NOTE:

NOTE:

NOTE: Two NC512m adapters are supported per ProLiant c-Class full height server in
type II x8 PCI Express mezzanine slots and one adapter per a type II x8 PCI Express
mezzanine slot in a half height server. For more information, see the Mezzanine Slot
Compatibility matrix within the HP NC512m Dual Port 10GbE Multifunction BL-c
Adapter QuickSpecs:

http://h18004.www1.hp.com/products/servers/networking/nc512m/index.html

.

NOTE:

NOTE:

NOTE:

NOTE: The NC512m requires a minimum of 2 GB of server memory per NC512m
card and supports a maximum of 32 GB for Windows and 64 GB for Linux. NOTE:
Each port on the NC512m transmits from the server only at 20 Gbps full duplex per
port.

440910-B21

HP BladeSystem

HP BladeSystem

HP BladeSystem

HP BladeSystem
c-Class FC SAN

c-Class FC SAN

c-Class FC SAN

c-Class FC SAN
Interconnects

Interconnects

Interconnects

Interconnects

HP 4Gb Virtual Connect Fibre Channel Module for c-Class BladeSystem

409513-B21

16 port FC Pass-thru Module for c-Class BladeSystem

403626-B21

HP 8/12c SAN Switch c-Class BladeSystem

AJ820A

HP 8/24c SAN Switch c-Class BladeSystem

AJ821A

HP 8/24c SAN Switch Power Pack c-Class Enclosure

AJ822A

HP 8/12c Switch 12-pt c-Class Upgrade LTU

T5517A

HP Brocade 4/12 SAN Switch

AE370A

HP Brocade 4/24 SAN Switch Power Pack

AE371A

HP Brocade 4/24 SAN Switch

AE372A

HP Brocade 4/12 SAN Switch Upgrade LTU

AE373A

Cisco MDS 9124e 12 port Fabric Switch

AG641A

HP BladeSystem

HP BladeSystem

HP BladeSystem

HP BladeSystem
InfiniBand Interconnects

InfiniBand Interconnects

InfiniBand Interconnects

InfiniBand Interconnects

HP 4X DDR IB Switch Module for HP c-Class BladeSystem

410398-B21

Step 4: Select rack power distribution for installing the enclosure into a rack.

Step 4: Select rack power distribution for installing the enclosure into a rack.

Step 4: Select rack power distribution for installing the enclosure into a rack.

Step 4: Select rack power distribution for installing the enclosure into a rack.

NOTE:

NOTE:

NOTE:

NOTE: For use with the c3000 rack-able model only.
NOTE:

NOTE:

NOTE:

NOTE: A pair of PDUs must be ordered for AC Feed redundancy. If AC redundancy is not required, a single PDU or UPS may be
acceptable.

HP Monitored Power

HP Monitored Power

HP Monitored Power

HP Monitored Power
Distribution Unit

Distribution Unit

Distribution Unit

Distribution Unit

HP 8.6 kVA Monitored PDU, 30A (NA/JPN)

AF504A

HP 11 kVA Monitored PDU 16A (INTL)

AF508A

HP Modular Power

HP Modular Power

HP Modular Power

HP Modular Power
Distribution Unit

Distribution Unit

Distribution Unit

Distribution Unit

HP 8.3kVA Modular Distribution Unit 40 Amp (NA/JPN)

252663-D73

HP 8.3kVA Modular Distribution Unit 40 Amp (Intl)

252663-B32

HP 7.3kVA Modular Distribution Unit 32 Amp (Intl)

252663-B31

HP 4.9kVA Modular Distribution Unit 24 Amp (NA/JPN)

252663-D72

HP Two C-13 PDU Extension Bars

AF500A

Uninterruptible Power

Uninterruptible Power

Uninterruptible Power

Uninterruptible Power
Systems - Rack Mountable

Systems - Rack Mountable

Systems - Rack Mountable

Systems - Rack Mountable

HP rack-mountable R5500 UPS (5000VA / 4500 watts)

NOTE:

NOTE:

NOTE:

NOTE: The R5500 includes four c-13 PDU Extension bars.
NOTE:

NOTE:

NOTE:

NOTE: The R5500 supports 4 power supplies in the Power Supply Redundant (N+1)
power mode

AF426A

HP Rack to Tower 5500 Conversion Kit

AF442A

QuickSpecs

HP BladeSystem c3000 Enclosure

HP BladeSystem c3000 Enclosure

HP BladeSystem c3000 Enclosure

HP BladeSystem c3000 Enclosure

Configuration Information Factory Integrated Models

DA - 12790 Worldwide — Version 12 — July 14, 2008
