Step 2A: Select additional optional enclosure options:

Additional C3000 Power

Additional C3000 Power
Supplies

Supplies

HP 1200W High Efficiency AC Common Slot Power Supply

NOTE:

NOTE: Meets Climate Savers Computing Initiative, 2007-2008
NOTE:

NOTE:

NOTE: AC power supplies include a C13 to C14 PDU power cord.

437572-B21

NOTE:

NOTE: Order additional power supplies, as determined by the use of the HP
BladeSystem Power Calculator.
NOTE:

NOTE:

NOTE: For a full enclosure, order 4 power supplies in a Power Supply Redundant
(N+1) configuration; order 6 power supplies in an AC Redundant (N+N)
configuration.

c-Class Active Cool Fan

HP BL c-Class Active Cool Fan

NOTE:

NOTE: For a full enclosure, order 2 additional (6 total) Active Cool Fans.

412140-B21

HP c3000 Enclosure DVD

HP c3000 Enclosure DVD
Drive

Drive

HP c3000 Enclosure DVD Drive

437577-B21

HP c3000 KVM Modules

HP c3000 KVM Modules
and Adapters

and Adapters

HP c3000 KVM module

NOTE:

NOTE: For use with in-rack KVM switches.

437575-B21

KVM Adapter for KVM switches with internal media drives

NOTE:

NOTE: Order one KVM Adapter per c3000 enclosure, to support KVM switches
accepting RJ45 cables (P/N's AF600A, AF601A, or AF602A). Please see Options
section of this QuickSpecs for additional product information.

AF603A

Other Enclosure Options

Other Enclosure Options HP BLc3000 Rack Rails

NOTE:

NOTE: For use with the c3000 rack-able (437507-B21) model.

437576-B21

HP Insight Control for

HP Insight Control for
BladeSystem Licenses

BladeSystem Licenses

HP c-Class Insight Control Environment for BladeSystem, 8 server blade licenses
including 1 year of 24x7 Technical Support and Updates

439034-B23

Optional Power Cords

Power Cord, C20 C13, 15A, Universal Jumper, 2m

NOTE:

NOTE: For use with PDU's accepting C20 power cords.

AF590A

Step 3: Select additional (one to four) interconnects.

NOTE:

NOTE: Interconnect Bay 1 must contain one of the "Ethernet" interconnect modules For additional information on Interconnect
Options, please visit:
HP BladeSystem c-Class Interconnect QuickSpecs:

http://h18000.www1.hp.com/products/quickspecs/12524_div/12524_div.html

HP BladeSystem

HP BladeSystem
c-Class Ethernet

c-Class Ethernet

c-Class Ethernet
Interconnects

Interconnects

HP 1/10Gb-F Virtual Connect Ethernet Module for c-Class BladeSystem

447047-B21

HP BladeSystem c-Class Virtual Connect 1Gb SX SFP

453151-B21

HP BladeSystem c-Class Virtual Connect 1Gb RJ-45 SFP Opt Kit

453154-B21

HP 1Gb Virtual Connect Ethernet Module for c-Class BladeSystem

NOTE:

NOTE: This module must be upgraded to VC Management firmware v1.20 or greater.

399593-B22

Ethernet Pass-Through Module for HP BladeSystem

406740-B21

Cisco Catalyst Blade Switch 3120X for HP

451439-B21

Cisco Catalyst Blade Switch 3120G for HP

451438-B21

Cisco Catalyst Blade Switch 3020 for HP c-Class BladeSystem

410916-B21

GbE2c Ethernet Blade Switch for HP c-Class BladeSystem

410917-B21

GbE2c Layer 2/3 Ethernet Blade Switch for HP c-Class BladeSystem

438030-B21

HP 1:10 Gb Ethernet BL-c Switch

438031-B21

HP 10Gb Ethernet BL-c Switch

NOTE:

NOTE: The purchase the HP 10Gb Ethernet BL-c Switch, also requires the purchase of
one (1) HP NC512m Dual Port 10GbE Multifunction BL-c Adapter (P/N 440910-B21)
per server blade that requires 10Gbit support.
NOTE:

NOTE:

NOTE: The HP BladeSystem c-Class Network Interconnects ship as single units. The
above interconnects must be ordered in quantities of two for redundant configurations.

445860-B21

QuickSpecs

HP BladeSystem c3000 Enclosure

Configuration Information Factory Integrated Models

DA - 12790 Worldwide — Version 12 — July 14, 2008
