Installing the Fibre Channel to SCSI Router for the
NonStop NS-Series Server
M8201R Fibre Channel to SCSI Router Installation and User’s Guide — 529971-005
3 -5
Installation
6. Tighten the screws by hand to secure the cable to the unit. Do not use a
screwdriver.
7. Connect the supplied differential terminator to SCSI port 2. See Figure 3-5 on
page 3-4 for the location.
8. Tighten the screws by hand to secure the terminator to the tape drive. Do not use a
screwdriver.
9. Attach the power cord to the AC power receptacle on the tape drive. See
Figure 3-5 for the location. Then plug the other end into an AC power outlet.
10. Connect the other end of the fiber cable to the Fibre Channel ServerNet adapter
(FCSA) on the NonStop NS-series server. For the location of the FCSA, see
Figure 3-6 on page 3-6.
Note. The tape drive does not have protection against lightning surges. Customers in high risk
areas should use external surge protection rated for use in their location and be able to handle
the power demand of the tape drive.
