RGB ON SCREEN DISPLAY
RESET
Set HORIZONTAL POSITION, VERTICAL POSITION, HORIZONTAL CLOCK and CLOCK
PHASE to factory preset, for current RGB format.
V POSITION
H POSITION
AUTO ADJUST
SET UP
RESET
CLOCK PHASE
HORIZONTAL CLOCK
INPUT LEVEL
RGB2 INPUT
0
0
+22
0
MODE:1
0.7V
:
:
:
:
:
:
:
:
SEL
TO RESET MOVE
EXIT
TO QUIT
RGB MODE MENU Press down on THUMB STICK to RESET to factory
preset settings.
CLOCK PHASE
Adjusts the phase to correct blurred or unstable images.
Use THUMB STICK
̇, ̈ to adjust the clock phase.
Press the MENU button to return to previous menu item.
Press EXIT to quit.
V POSITION
H POSITION
AUTO ADJUST
SET UP
RESET
CLOCK PHASE
HORIZONTAL CLOCK
INPUT LEVEL
RGB2 INPUT
0
0
+22
0
MODE:1
0.7V
:
:
:
:
:
:
:
:
̇ ̈
CHANGE
VALUE
MOVE EXIT
TO QUIT
RGB MODE MENU
HORIZONTAL CLOCK
Adjusts the pixel clock frequency to reduce the vertical stripe.
V POSITION
H POSITION
AUTO ADJUST
SET UP
RESET
CLOCK PHASE
HORIZONTAL CLOCK
INPUT LEVEL
RGB2 INPUT
0
0
+22
0
MODE:1
0.7V
:
:
:
:
:
:
:
:
̇ ̈
CHANGE
VALUE MOVE
EXIT
TO QUIT
RGB MODE MENU
Use THUMB STICK
̇, ̈ to adjust the horizontal
clock. Press the MENU button to return to previous
menu. Press EXIT to quit.
NOTE: Due to varying signal content, you may see vertical or horizontal lines bend occasionally in RGB mode. However, this
phenomenon is not a defect. It’s caused by a lack of picture content due to under-scanning in RGB mode.
