72
NOTE: • Press SELECT to AUTO ADJUST the RGB mode.
• The other functions do not operate while AUTO ADJUST is in progress.
• Allow the Plasma TV to warm up for 20 minutes before performing AUTO ADJUST.
• Select a bright image for display while AUTO ADJUST takes place.
• If AUTO ADJUST terminates unsuccessfully, try AUTO ADJUST again. If AUTO ADJUST fails several times in
succession, try using manual adjustment.
• Always reset AUTO ADJUST when setting new display setting or when changing to a new
external component.
RGB ON SCREEN DISPLAY
V POSITION
This feature allows you to adjust the vertical position in RGB mode.
Use THUMB STICK
̇, ̈ to adjust the vertical
position.
Press MENU button to return to previous menu item.
Press EXIT to quit.
V POSITION
H POSITION
AUTO ADJUST
RESET
CLOCK PHASE
HORIZONTAL CLOCK
INPUT LEVEL
RGB2 INPUT
0
0
+22
0
MODE:1
0.7V
:
:
:
:
:
:
:
:
CHANGE
VALUE
MOVE EXIT
TO QUIT
̇ ̈
RGB MODE MENU
H POSITION
This feature allows you to adjust the horizontal position of the display.
Use Left/Right cursors to adjust the horizontal position.
Press the MENU button to return to previous menu item.
Press EXIT to quit.
V POSITION
H POSITION
AUTO ADJUST
SET UP
RESET
CLOCK PHASE
HORIZONTAL CLOCK
INPUT LEVEL
RGB2 INPUT
0
0
+22
0
MODE:1
0.7V
:
:
:
:
:
:
:
:
CHANGE
VALUE MOVE
EXIT
TO QUIT
̇ ̈
RGB MODE MENU
V POSITION
H POSITION
AUTO ADJUST
SET UP
RESET
CLOCK PHASE
HORIZONTAL CLOCK
INPUT LEVEL
RGB2 INPUT
0
0
+22
0
MODE:1
0.7V
SEL
TO START MOVE
EXIT
TO QUIT
:
:
:
:
:
:
:
:
RGB MODE MENU
HORIZONTAL POSITION, VERTICAL POSITION, HORIZONTAL CLOCK and CLOCK PHASE
for current RGB format are adjusted automatically. AUTO ADJUST
Press SELECT to select AUTO ADJUST.
