Parts list - see hardware identifier – Huffy M731321 User Manual
Page 6
6
ID# M731321
11/05
PARTS LIST - See Hardware Identifier
Item Qty. Part No. Description
1
1
206657
Tank, (Black)
2
1
200628
Wheel Axle
3
2
226401
Wheel, 4“ (Black)
4
1
90021701 Top Pole Section
5
1
904840
Middle Pole Section
6
1
900136
Bottom Pole Section
7
1
202820
Rod, 3/8 O.D. x 4-3/4 Long
8
1
202822
Eyebolt, 3/8-16 x 2-1/2 Long
9
7*
203063
Nylon Insert Lock Nut, 3/8-16
10
2
906206
Tank Strut
11
1
201625
Bolt,Yellow Dichromate, 5/16-18 X 3.60" Long
12
6
203218
Washer, Flat, 3/8 I.D.
13
2
203099
Nylon Insert Lock Nut, 5/16-18
14
1
206219
Cap, Pole Top 3”
15
6
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
16
8
203100
Nut, Hex Flange, 5/16-18
17
2
201651
Spacer .500 I.D. x .25 Long
18
5
204804
Screw, Phillips Head, 3/4 Long
19
1
200627
Wheel Bracket
20
1
Rim
21
5
206340
Nut 1/2-13
22
5
206304
Bolt 1/2-13 x 6-5/16 Long
23
1
202739
Bolt 5/16-18 x 1.75 Long
24
2
203617
Plug Cap
25
1
211262
Label, Height Adjustment and Moving
26
1
Net
27
1
200209
Pole Mount Bracket
28
2
203231
Bolt, Carriage, 5/16-18 x 3.5 Long
29
2
90096401 Backboard Bracket
30
1
203472
Spring, Black, Slam Jam
31
1
200318
Bracket, Reinforcement, Slam Jam
32
1
900033
Bracket Slam Jam
33
1
200212
Trigger
34
1
206990
Reinforcement Bracket
35
4
204961
Bolt, Hex 3/8-16 x .625 Long
36
1
203796
T-Bolt, 3/8-16 x 5” Long
37
1
204872
Labels Height Indicator
38
1
203470
Washer Flat, Slam Jam
39
2
203678
Bolt, Hex, 3/8-16 x 6.5" Long
40
1
203795
Nut, Special, Slam Jam
41
2
902537
Lower Elevator Tubes
42
4
201642
Spacer .530 I.D. x.5 O.D. x .63 Long
43
1
204838
Spring, Elevator
44
2
900184
Upper Elevator Tubes
45
1
200215
Cross Pin
46
1
200214
Locking Pin
47
1
200211
Left Handle
48
1
200210
Right Handle
49
1
900006
Adjustment Tube - Upper
50
1
200257
Spring
51
2
202862
Spacer .563 I.D. x 1.19 Long
52
1
908109
Adjustment Rod - Lower
NOTE: Hardware kit is designed for more than one style of basketball system. Not all hardware
will be used.
* You may have extra parts with this model.
