23 11/05 ID# M731321
13
23
27
52
10.
Insert lower adjustment rod (52) into bottom of adjustment tube (49), pull trigger to allow
lower adjustment rod to move about mid-way into adjustment tube (49), release the trigger
so the lower adjustment rod (52) locks into position midway inside the adjustment tube (49).
Attach the lower adjustment rod (52) to elevator bracket (27) using bolt (23) and nut (13) as
shown.
52
49
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
DO NOT LEAVE
ASSEMBLY
UNATTENDED WHEN
EMPTY; IT MAY TIP
OVER.
WARNING!
