26 ID# M731321 11/05
NOTE: Slide counterbalance
spring against elevator tubes.
Install net (26) as shown.
13.
B.
D. C.
A.
Lock elevator system into highest position (so the backboard is as high as it will go). Apply 10
ft. height indication sticker (37) to adjustment rod (52) directly below arrow on handle as shown.
Move elevator system to the next position and apply the 91/2 ft. sticker. Repeat until all height
settings have been labeled. (8-10 ft.) 14.
37
52
20
26
