Important – Huffy M731321 User Manual
Page 16
16
ID# M731321
11/05
44
2.
41
Identify elevator tubes (41 and 44).
Toward Pole
Upper Elevator tube
Lower Elevator tube
Assemble backboard brackets (29) using bolts (35), and nuts (9) as shown.
1.
35
35
35
35
29
29
Test fit bolts into holes of brackets
and carefully rock them in a
circular motion to ream out paint
from holes if necessary.
IMPORTANT!
9
9
29
NOTE ORIENTATION
Toward Board
