Local port operation 54

To access the Config dialog box, from the Main dialog box ("

Accessing the Main dialog box

" on page

), click Commands>Config. The Config dialog box appears.

Running system diagnostics

You can validate the firmware CRCs and interface adapter status for the console switch through the Run

Diagnostics command.
To access the Diagnostics dialog box, click Commands>Run Diagnostics.

Test Description

Firmware CRCs

Validates the current firmware images stored in the system FLASH by comparing a
CRC value on each image and comparing those results to the expected values.

Remote User Video
(digital only)

Verifies that all the video channel subsystems are accessible, functional, and
performing basic register level tests.
