Removal and replacement procedures 28
Hard drive backplane
To remove the component:
1. Power down the server blade (on page 23 ).
2. Remove the server blade (on page 23 ).
3. Remove the access panel (" Access panel " on page 24 ).
4. Remove all hard drives (" Hard drive " on page 25 ).
5. Remove all hard drive blanks (" Hard drive blank " on page 24 ).
CAUTION: Remove all hard drives and hard drive blanks before removing the hard drive
backplane.
6. Remove the hard drive backplane.
To replace the component, reverse the removal procedure.
Front panel/hard drive cage assembly
To remove the component:
1. Power down the server blade (on page 23 ).
2. Remove the server blade (on page 23 ).
3. Remove the access panel (" Access panel " on page 24 ).
4. Remove all hard drives (" Hard drive " on page 25 ).
5. Remove all hard drive blanks (" Hard drive blank " on page 24 ).
6. Remove the hard drive backplane (" Hard drive backplane " on page 28 ).
