HP PRO 2000 - Manual (Page 9)

Unit Environment and Unit Environment and Unit Environment and Unit Environment and
Operating Conditions
Operating Conditions Operating Conditions Operating Conditions
General Unit Operating Guidelines General Unit Operating Guidelines General Unit Operating Guidelines General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and
cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required
airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are
subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer.
Lint, dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must
be provided on the enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Temperature Range Temperature Range Temperature Range Operating Operating Operating Operating 41° to 95° F (5° to 35° C)
Non-operating Non-operating Non-operating Non-operating -22° to 149° F (-30° to 65° C)
Relative Humidity Relative Humidity Relative Humidity Relative Humidity Operating Operating Operating Operating 10% to 90% (non-condensing at ambient)
Non-operating Non-operating Non-operating Non-operating 5% to 95% (non-condensing at ambient)
Maximum Altitude Maximum Altitude Maximum Altitude Maximum Altitude
(unpressurized) Operating Operating Operating Operating 10,000 ft (3048 m)
Non-operating Non-operating Non-operating Non-operating 30,000 ft (9144 m)
NOTE: NOTE: NOTE: NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 7500 ft (2286 m) above
sea level, no direct sustained sunlight. Maximum rate of change is 7.5 deg C/Hr. The upper limit may
be limited by the type and number of options installed.
System Board System Board System Board System Board Processor Processor Processor Processor Socket T; LGA775 industry standard Micro ATX form factor
Support single Intel Core 2 Duo and Core 2 Quad, Pentium dual-core, or
Celeron processors
Chipset Chipset Chipset Chipset Intel G41 Express
Intel I/O Controller Hub 7 (ICH7)
Front Side Bus Frequency Front Side Bus Frequency Front Side Bus Frequency Front Side Bus Frequency 800/1066/1333 MHz
Memory Memory Memory Memory DDR3 SDRAM
2 x DIMM slots
Integrated Graphics Integrated Graphics Integrated Graphics Integrated Graphics Intel Graphics Media Accelerator (GMA) X4500
Audio Audio Audio Audio Realtek ALC662 HD Audio compatible codec with two channel audio 3D
audio compliant with AC'97 rev. 2.3
LOM LOM LOM LOM Realtek RTL8111DL
Storage Storage Storage Storage Four Serial ATA interfaces
Expansion Slots Expansion Slots Expansion Slots Expansion Slots 1 x PCI Express x1 slots
1 x PCI Express x16 slot
2 X PCI
BIOS BIOS BIOS BIOS SPI FLASH ROM
Industrial Standard Industrial Standard Industrial Standard Industrial Standard PCIe compliant
USB 2.0
Rear I/O Ports Rear I/O Ports Rear I/O Ports Rear I/O Ports 1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
QuickSpecs
HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC
System Details
DA - 13494 Worldwide — Version 4 — November 29, 2010 Page 9
