a.
b.
c.
d.
e.
f.
g.
Compliance standards Compliance standards Compliance standards Compliance standards EMC Emissions:
FCC Part 15, Subpart B - Unintentional Radiators, Class B Computing
Devices for Home & Office Use
CISPR22: 1997/EN 55022:1998 - Class B - Limits and methods of
measurement of radio disturbance characteristics of Information
Technology Equipment
Canadian Standard ICES-003 is equivalent to CISPR22
Japanese VCCI
Taiwanese Standard BSMI
Australian C-Tick
Korean (KCC)
EMC Immunity:
CISPR 24:1997/EN 55024:1998 - Information Technology Equipment -
Immunity Characteristics - Limits and Methods of Measurement.
ATI HD4350 (512 MB) PCIe x16 Graphics Controller display resolutions and refresh rates ATI HD4350 (512 MB) PCIe x16 Graphics Controller display resolutions and refresh rates ATI HD4350 (512 MB) PCIe x16 Graphics Controller display resolutions and refresh rates ATI HD4350 (512 MB) PCIe x16 Graphics Controller display resolutions and refresh rates
NOTE: NOTE: NOTE: NOTE:
Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
All standard VGA text/graphics modes are supported in addition to table below.
All modes not highlighted are selectable Windows® desktop modes. Highlighted modes should
not be selectable as Windows® desktop modes (they are for DirectX™)
All modes up to and including 1600x1200 must support the video overlay at all refresh rates.
Analog Resolution Analog Resolution Analog Resolution Analog Resolution Depth(bpp) Depth(bpp) Depth(bpp) Depth(bpp) CRT Maximum Refresh Rate (Hz) CRT Maximum Refresh Rate (Hz) CRT Maximum Refresh Rate (Hz) CRT Maximum Refresh Rate (Hz)
- VGA AND DVI-A (ANALOG) - VGA AND DVI-A (ANALOG) - VGA AND DVI-A (ANALOG) - VGA AND DVI-A (ANALOG)
CRT Maximum Refresh CRT Maximum Refresh CRT Maximum Refresh CRT Maximum Refresh
Rate (Hz) - DVI-I Rate (Hz) - DVI-I Rate (Hz) - DVI-I Rate (Hz) - DVI-I
(DIGITAL) (DIGITAL) (DIGITAL) (DIGITAL)
CRT Maximum Refresh CRT Maximum Refresh CRT Maximum Refresh CRT Maximum Refresh
Rate (Hz) - HDMI Rate (Hz) - HDMI Rate (Hz) - HDMI Rate (Hz) - HDMI
800 x 600 16, 32 60, 75 60, 75 60, 75
1024 x 768 16, 32 60, 75 60, 75 60, 75
1152x648 16, 32 NA NA 59, 60
1152x864 16, 32 NA 60, 75 59, 60
1280x720 16, 32 NA 60 50, 59, 60
1280x768 16, 32 75 60, 75 60, 75
1280x960 16, 32 60 60 60
1280 x 1024 16, 32 60, 75 60, 75 60, 75
1440x900 16, 32 60 60 60
1600 x 1200 16, 32 60 60 60
1680x1050 16, 32 60 60 60
1920 x 1080 16, 32 NA 59, 60 50, 59, 60
1920 x 1200 16, 32 59, 60 59, 60 59, 60
ATI Radeon HD ATI Radeon HD ATI Radeon HD ATI Radeon HD
4550 (256MB DH)
4550 (256MB DH) 4550 (256MB DH) 4550 (256MB DH)
PCIe x16 Graphics
PCIe x16 Graphics PCIe x16 Graphics PCIe x16 Graphics
Card
Card Card Card
Input/Output Input/Output Input/Output Input/Output
connectors
connectors connectors connectors
DMS-59
S-video connector
Board display options Board display options Board display options Board display options Supports two displays via included DMS-59 to dual VGA cable or 2 DVI monitors via
optional DMS-59 to dual DVI cable kit part number: DL139A. 4-pin mini-DIN S-video
connector for TV output
Display max resolution Display max resolution Display max resolution Display max resolution 1900 x 1200 digital, 2048 x 1536 analog
QuickSpecs
HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC
Technical Specifications
DA - 13494 Worldwide — Version 4 — November 29, 2010 Page 27
