1600 x 1200 60 Hz
1920 x 1200 * 60 Hz
1920 x 1440 ** 60 Hz
2560 x 1600 ** 60 Hz
* Reduced blanking timings used when connected to a single-link DVI monitor
** Requires a dual-link DVI capable monitor
NVIDIA GeForce 315 NVIDIA GeForce 315 NVIDIA GeForce 315 NVIDIA GeForce 315
1GB PCIe x16 Card
1GB PCIe x16 Card 1GB PCIe x16 Card 1GB PCIe x16 Card
Form Factor Form Factor Form Factor Form Factor ATX Full Height
Display max resolution Display max resolution Display max resolution Display max resolution Analog VGA: 2048x1536x32bpp@85Hz
DVI: 2560 x 1600 x32bpp @60Hz
Input/Output connectors Input/Output connectors Input/Output connectors Input/Output connectors DVI-I +VGA
Board configuration Board configuration Board configuration Board configuration Specification Specification Specification Specification Description Description Description Description
Graphics Chip D10M2-20 (GT216-200-A2)
Core clock 625 MHz
Memory clock 790 MHz
Frame buffer 1GB DDR3, 128-bit
Core power Core power Core power Core power 52 W (Max board power)
NVIDIA GeForce 315 (1GB) PCIe x16 Graphics Controller display resolutions and refresh rates NVIDIA GeForce 315 (1GB) PCIe x16 Graphics Controller display resolutions and refresh rates NVIDIA GeForce 315 (1GB) PCIe x16 Graphics Controller display resolutions and refresh rates NVIDIA GeForce 315 (1GB) PCIe x16 Graphics Controller display resolutions and refresh rates
NOTE: NOTE: NOTE: NOTE: Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.
Analog Resolution Analog Resolution Analog Resolution Analog Resolution Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate
640 x 480 85 Hz
800 x 600 85 Hz
1024 x 768 85 Hz
1280 x 1024 85 Hz
1600 x 1200 85 Hz
1920 x 1080 85 Hz
1920 x 1200 85 Hz
1920 x 1440 85 Hz
2048 x 1536 85 Hz
Digital Resolution Digital Resolution Digital Resolution Digital Resolution Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate Maximum Refresh Rate
640 x 480 60 Hz
800 x 600 60 Hz
1024 x 768 60 Hz
1280 x 1024 60 Hz
1600 x 1200 60 Hz
1920 x 1200 * 60 Hz
1920 x 1440 ** 60 Hz
2560 x 1600 ** 60 Hz
* Reduced blanking timings used when connected to a single-link DVI monitor
** Requires a dual-link DVI capable monitor
NVIDIA G210 (512MB) NVIDIA G210 (512MB) NVIDIA G210 (512MB) NVIDIA G210 (512MB)
PCIe x16 Card
PCIe x16 Card PCIe x16 Card PCIe x16 Card
Form Factor Form Factor Form Factor Form Factor ATX Full Height
QuickSpecs
HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC
Technical Specifications
DA - 13494 Worldwide — Version 4 — November 29, 2010 Page 23
